INGRID X Crankset - Raw
X for cross country but even for a cross-sectoral experience from gravel to trail riding.Ā This is the new alloy crankset in our way for the modern off road bikes.
Sister of the R2 type, it is born to have lightness (as much as itās possible) and simplicityAfter some month of iteration between shapes and FEM, we reached this new āradical as cleanā and definitive structure for this new crankset: 2 drilled ātubesā at sides and a machined matrix for a perfect stifness/weight ratio in aluminum cncād cranksets.
Compatible with any of our chainrings and spindles.
Specifications
Crank length: S (166.25) | M (170) | L (173.75)
Spindle: 30 mm
Chainrings: All INGRID chainrings and spider | SRM Origin PM (with dedicated spindle)
Chain compatibility: 11s, 12s, 13s (Campagnolo Ekar, SRAM Flattop)
K-factor: 91.5 mm (L131) | 96.5 mm (L136) | 101.5 mm (L141)
Q-factor: 163 mm (L131) | 168 mm (L136) | 173 mm (L141)
Chainline: 49.5 mm (L131) | 52 mm (L136) | 54.5 mm (L141)
Chainline (aero chainrings): 47.5 mm (L131) | 50 mm (L136) | 52.5 mm (L141)
Color: Raw (no finish) | Black | Titanium | Special colors
Mfr Claimed Weight
480 g (M cranks, L131 spindle, without chainring)
